Commonly used pneumatic conveying systems include dilute phase conveying and dense phase conveying. These types can be specifically distinguished by how they work. In addition, each pneumatic conveying system type can convey material by pressure or vacuum methods. Next, we'll explain each stage more thoroughly. Dilute phase pneumatic conveying is described as the process of pushing (pressure) or pulling (vacuum) particles suspended in air from one location to another. Airborne particles are continuously transported at low pressure and high speed. As mentioned above, there are two main types of dilute phase transport. These types are listed and described below:

Dilute Phase Pressure Conveying - This method is the most common method used in pneumatic conveying systems for conveying non-abrasive, resilient, dry materials with low bulk density over long distances. Some examples of materials used in this method are plastic granules, sugar and flour.

How it works: In this type, the blower, usually a positive displacement blower, is fixed at the very beginning of the pneumatic conveying system to provide a large volume of low pressure air. Adjacent to the blower is a feeder and rotary airlock valve that methodically "feed" material into the line. As material enters the production line, the air flow provided by the blower pushes and suspends the particles, quickly from where they enter to another destination. This method is often used to transport material from a single destination to multiple locations.

Dilute Phase Vacuum Conveying - This method is used to convey materials that are compacted or compressed together under pressure. Some examples of these pressure sensitive materials are wood shavings and fibers. Dilute phase vacuum delivery is commonly used in central vacuum cleaning systems that require many pipes to deliver material to a single location or collection point.

How it works: Dilute phase vacuum conveying works in the exact opposite of pressure conveying, positive displacement vacuum provides negative pressure to pull material from the storage hopper. A vacuum pump is placed at the other end of the line to provide suction to pull material from one location to another. The negative pressure in the pneumatic conveying system is controlled by the vacuum relief valve to ensure that the right amount of material reaches the destination or multiple locations.

科里时丨常用的气力输送系统有几种?真空输送的工作原理是什么?



Dense phase pneumatic conveying is described as the process of pushing (pressure) or pulling (vacuum) particles that are not suspended in the conveying air. Densely conveyed materials are conveyed at high pressure and at low or low speed. The two main types of dense phase transport are listed and described below:

Dense Phase Pressure Conveying - This method is typically used to convey abrasive or brittle materials over long distances at very low speeds. Materials typically transferred by this method are hazelnuts, cocoa beans, grains, candy and glass granules. Pneumatic conveying systems are best known for their benefits of stopping or starting on a conveyor line full of material.

How it works: The material delivered by this method is first loaded into a pressure vessel or blow bottle. Once the blow bottle is completely filled, the material discharge and inlet valves are closed and compressed air is pushed into the container. Compressed air forces the material from the container into the conveyor line at its destination. After the transfer of all materials in the vessel and lines is complete, the process begins again. Air jets or nozzles are usually attached to the length of the conveyor line to help lift the material.

科里时丨常用的气力输送系统有几种?真空输送的工作原理是什么?



Dense Phase Vacuum Conveying - This type is used for conveying abrasive or brittle materials over short distances at low speeds. Dense phase vacuum conveying is commonly used to unload material from railcars and trucks in a fluidized state. It is also used in pharmaceutical and food applications.

How it works: These types of systems use a vacuum pump to transport material from a silo or hopper to a receiving vessel called a vacuum hopper. When the vacuum hopper is full, the material is discharged to the target silo. The process repeats once all the material has been delivered from the silo or hopper.

Pneumatic conveying is an extremely efficient method of conveying materials used by all walks of life to ensure the safe delivery of their resources and products. If you have any questions about pneumatic conveying system design, please contact us today! We also offer a variety of PD blower kits that can be engineered and engineered to your pneumatic conveying specifications.
